Unlimited Rebate Planer 750 W TRP UL

17-position depth control for precise material removal, lock-off switch and low-vibration front handle for added comfort. Left or right rear dust extraction. Power indicator. Removable blade drum system allows fitment of interchangeable sanding drum. Cutting capacities: width 82mm, depth 3mm. Weight 3.9kg.

• 0 - 3mm adjustable depth of cut allows removal in one pass
• Variable speed control adjusts the drum speed to suit the material
• 3-Blade drum provides a higher rate of material removal (46,500 cuts per minute)
• Bail handle for improved ergonomics and increased control
• Left or right rear dust extraction allows the dust/chips to be directed to either side of the workpiece
• Drum guard protects against exposed blades when rebating
• Spindle lock button for easy drum changes
• Parking stand protects the blades and workpiece from damage on run down
• Power-on neon increases operator safety

Technical Specification

• Blade Type 3 x Reversible HSS
• Cuts Per Minute CPM 46,500cpm
• Material - Primary Construction Aluminium PA6 + GF30
• No Load Speed 15,500rpm
• Planing Depth 0 - 3mm
• Planing Width 82mm
• Power 750W
• Power On Indicator Yes
• Product Height 165mm
• Product Length 300mm
• Product Weight 3.9kg
• Product Width 170mm
• Sound Power LW 98dB
• Sound Pressure LP 87dB

What's in the box - 01 Sanding drum with sanding sleeve

What's in the box - 02 Planing drum (HSS 3 blade) on machine

What's in the box - 03 Wrench and hex spanner

What's in the box - 04 Dust extraction bag and adaptor

What's in the box - 05 Guide fence

Included Accessories

• Sanding drum with sanding sleeve
• Planing drum (HSS 3 blade) on machine
• Dust extraction bag and adaptor
• Guide fence
