Self-levelling crossline laser set autoCROSS 3

Pulsed, self-levelling crossline laser autoCROSS 3

Basic instrument with receiver

• Self-levelling crossline-laser.
• Horizontal and vertical lines can be switched on separately.
• Can also be used with receiver by pulsed laserdiodes.
• Delivery with transport case, including batteries.

•  Type of laser red diode laser, wave length 635 nm
• Output laser class 2
• Levelling fully automatic (pendulum)
• Self-levelling range ± 4°
• Accuracy ± 3 mm/10 m
• Range with receiver minimum 30 m
• Power supply 3 x 1.5 V batteries Type AALR6
• Aperture angle 140° vertical, 120° horizontal
• Out of level indicator blinking laser lines
• Tripod connection size 1/4“
• Operating temperature -10° C to 50° C
• Storage temperature -20° C to 70° C
• Dimensions 120 x 95 x 62 mm

Technical Data Adapter:

• Tripod connection size 1/4“ and 5/8“
• Fastening magnets, tripod
• Dimensions 115 x 65 x 40 mm

Delivery in transport case, incl. batteries
